Antenna has both RHCP and LHCP, use the correct port for the polarization of your choice.
SMA and RP-SMA attachments included in the same package
Specifications:
- Brand Name : Realacc
- Center frequency: 5.8 GHz
- Bandwidth: 660 MHz (5.47 – 6.13 GHz)
- Matching: S11 < -20 dB, VSWR < 1.22 (at center frequency)
- Axial ratio: < 1.3
- Antenna gain: 8 dBi
- Half power beam width: 65° (horizontal and vertical)
- Radiation efficiency: 90%
- Diameter: 45mm
Package:
1 x Antenna Plate
1 x SMA Antenna Extension Cable
1 x SMA Female to RP-SMA Male Adpater
1 x SMA Male Terminal Connector
